Jackdaw

HEMERIA Jackdaw tethered aerostat systems are easy to use and competitive for airborne and persistent ISR missions.

Download the product data sheet
//Scan
  • Easy and quick to deploy
  • Visible from afar, benefit from a deterrent effect
  • 24/7 airborne coverage of a wide area

Approved on

French Homeland Security

Surveillance of sensitive areas

Frontex

Border surveillance

French Ministry of Defense

Serving the French Armed Forces

Main fields of operation

  • Border surveillance
  • Protection of sensitive sites, military camps and navy vessels
  • Maritime awareness
  • Deployment of temporary and secure telecom relay
  • Communication and signals intelligence
  • Environment and pollution monitoring

Characteristics

  • We provide a complete Jackdaw system, which includes the tethered aerostat platform, the payload and the Command & Control ground station. Our standard offer features an optronic sensor and the dedicated C2.
  • Other sensors are available on request.We also offer to integrate your own payload.
Jackdaw

Dimensions

Two envelope dimensions are available : 12.8 m and 16.2 m

Flying height

Up to 700 meters

Payload

Up to 80 kg ● Payload options: camera, radar, telecom, radio, SIGINT

Persistence

Up to 30 days

Wind speed limit

Up to 54 nd / 100 km/h

Deployment

Depends on the size of the envelope

Transport and storage

Several options available: fixed or mobile docking station
